AMD Ryzen 5 6600U (6C/12T, 2.9/4.5GHz, 3MB L2/16MB L3), 8GB LPDDR5-6400, 256GB SSD M.2 2242 PCIe 4.0x4 NVMe, 13.3" WUXGA (1920x1200) IPS 300nits Anti-glare 100% sRGB Dolby Vision, AMD Radeon 660M Graphics, Wi-Fi 6E 11ax 2x2 BT5.1, FHD 1080p with Privacy Shutter, Windows 11 Pro

---

Perfectly portable performance

- Lightweight 13.3" SMB laptop with premium aluminum design

- Powered by AMD Ryzen™ 6000 Series Mobile Processors

- Long battery life & Rapid Charge technology

- Vast storage & responsive memory with M.2 PCIe SSD & dual-channel LPDDR5 options

- Speedy & secure power button activated by touch fingerprint reader

- AI-based technology for smart meetings enables notetaking, translations, & more

---

Design
Housing material	Aluminium
Form factor	Clamshell
Colour name	Arctic Grey
Product colour	Grey
Product type	Laptop

Display
High Dynamic Range (HDR) technology	Dolby Vision
Colour gamut	100%
RGB colour space	sRGB
Display brightness	300 cd/m²
Anti-glare screen	Yes
LED backlight	Yes
Native aspect ratio	16:10
Panel type	IPS
HD type	WUXGA
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	33.8 cm (13.3")

Processor
Motherboard chipset	AMD SoC
Processor cache type	L3
Processor cache	16 MB
Processor cores	6
Processor boost frequency	4.5 GHz
Processor frequency	2.9 GHz
Processor model	6600U
Processor generation	AMD Ryzen 6000 Series
Processor family	AMD Ryzen™ 5
Processor manufacturer	AMD

Memory
Memory channels	Dual-channel
Maximum internal memory	8 GB
Memory form factor	On-board
Memory clock speed	6400 MHz
Internal memory type	LPDDR5-SDRAM
Internal memory	8 GB

Storage
Card reader integrated	No
Optical drive type	No
SSD form factor	M.2
NVMe	Yes
SSD interface	NVMe, PCI Express 4.0
SSD capacity	256 GB
Number of SSDs installed	1
Total SSDs capacity	256 GB
Storage media	SSD
Total storage capacity	256 GB

Graphics
On-board graphics card model	AMD Radeon 660M
On-board graphics card family	AMD Radeon
On-board GPU manufacturer	AMD
Discrete graphics card model	Not available
Discrete graphics card	No
On-board graphics card	Yes

Audio
Number of microphones	2
Built-in microphone	Yes
Speaker power	2 W
Number of built-in speakers	2
Audio system	Dolby Audio
Audio chip	Realtek ALC3287

Camera
Privacy type	Privacy shutter
Privacy camera	Yes
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Front camera	Yes

Network
Bluetooth version	5.2
Ethernet LAN	No
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Mobile network connection	No
Bluetooth	Yes

Ports & interfaces
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB Power Delivery	Yes
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
HDMI ports quantity	1
USB4 Gen 3x2 ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1

Keyboard
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	UK English
Pointing device	Touchpad

Software
Trial software	Office
Operating system language	English
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Battery
Fast charging	Yes
Battery life (max)	14 h
Battery capacity (Watt-hours)	56 Wh
Battery technology	Lithium Polymer (LiPo)

Power
AC adapter power	65 W

Security
Password protection type	Power on, Supervisor, SSD
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Fingerprint reader	Yes
Cable lock slot type	Kensington
Cable lock slot	Yes

Operational conditions
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	8 - 95%
Storage temperature (T-T)	5 - 43 °C
Operating temperature (T-T)	5 - 35 °C

Certificates
Certification	EPEAT SilverENERGY STAR 8.0ErP Lot 3TCO CertifiedRoHS compliant
Compliance certificates	RoHS

Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Silver, ErP, TCO

Weight & dimensions
Height	14.9 mm
Depth	211 mm
Width	297 mm
Weight	1.23 kg

General
Product family	ThinkBook

Logistics data
Harmonized System (HS) code	84713000
